Cellular
Designed for WWAN communications, 3onedata’s 4G/5G industrial-grade cellular products provide resilient remote access. 3onedata’s cellular products support secure VPN communications, static and dynamic IP routing, port forwarding, and firewall functions to provide secure, reliable WAN communications for your devices.
-
<h1>DIN-Rail Mounting Industrial Indoor 5G Wireless Route</h1>
<p class="15">Support 1 Gigabit COMBO port (WAN/LAN, optional RJ45 or SFP slot), 3 Gigabit copper ports(LAN), 2 2.4G antenna interfaces, 2 5.8G antenna interfaces and 4 5G Sub- 6G antenna interfaces (2 RS-232, 2 RS-485/422, 2 CAN and 4 I/O are optional)</p>
<p class="15">CAN port and serial port support multiple operating modes like TCP Server, TCP Client, UDP Server, UDP Client, etc.</p>
<p class="15">I/O port supports working modes such as DI, Counter, DO and Pulse Output. DI channel and DO channel can be managed via Modbus TCP Master.</p>
<p class="15">Support 5G NR cellular wireless network, compatible with 3G/4G LTE all networks</p>
<p class="15">Support 2.4GHz and 5.8GHz dual bands</p>
<p class="15">Support 12~48VDC single power supply dual input, and WAN port supports 48VDC PoE power supply input</p>
<p class="15">Support -40~75℃ wide operating temperature range</p>
-
